| Model | Gauge Type | Pressure Range | Hose Length | Chuck Type |
|---|---|---|---|---|
| TGC090 | Inflator | 10-90 PSI | 12″ | Straight |
| TGC091 | Inflator | 10-90 PSI | 12″ | Ball |
| TGC092 | Inflator | 10-90 PSI | 12″ | Dual |
| TGC093 | Inflator | 10-90 PSI | 12″ | Clip-On |
| TGC100 | Inflator w/ Bleeder | 10-90 PSI | 12″ | Straight |
| TGC101 | Inflator w/ Bleeder | 10-90 PSI | 12″ | Ball |
| TGC102 | Inflator w/ Bleeder | 10-90 PSI | 12″ | Dual |
| TGC103 | Inflator w/ Bleeder | 10-90 PSI | 12″ | Clip-On |
| TGC120 | Inflator | 10-120 PSI | 12″ | Dual |
| TGC121 | Inflator | 10-120 PSI | 12″ | Ball |
| TGC122 | Inflator | 10-120 PSI | 12″ | Straight |
| TGC123 | Inflator | 10-120 PSI | 12″ | Clip-On |
| TGC128 | Inflator | 10-120 PSI | 36″ | Clip-On |
| TGC129 | Inflator | 10-120 PSI | 36″ | Lock-On |
| TGC130 | Inflator w/ Bleeder | 10-120 PSI | 12″ | Dual |
| TGC131 | Inflator w/ Bleeder | 10-120 PSI | 12″ | Ball |
| TGC132 | Inflator w/ Bleeder | 10-120 PSI | 12″ | Straight |
| TGC133 | Inflator w/ Bleeder | 10-120 PSI | 12″ | Clip-On |
| TGC138 | Inflator w/ Bleeder | 10-120 PSI | 36″ | Clip-On |
| TGC139 | Inflator w/ Bleeder | 10-120 PSI | 36″ | Lock-On |
| TGH1209A | Hose Assembly | n/a | 12″ | Clip-On |
| TGH1214A | Hose Assembly | n/a | 12″ | Straight |
| TGH1216A | Hose Assembly | n/a | 12″ | Dual |
| HPG2212 | Pencil Tire Gauge | 20-120 PSI | – | Ball |
| PG115 | Pencil Tire Gauge – 10-50lbs | – | – | Ball |
| PG2113 | Dual Foot Service Gauge – 10-130lbs | – | – | Dual |
| PG2212 | Pencil Tire Gauge – 20-120lbs | – | – | Dual |
| TGB060** | 2″ Dial Pressure Gauge | 0-60 PSI | – | Straight |
| TGB160** | 2″ Dial Pressure Gauge | 0-160 PSI | – | Straight |
| Tire Pressure Gauge Accessories | ||
|---|---|---|
| Model | Description | Pressure Range (PSI) |
| TGA060 | Dual Extension Chuck | 0-60 PSI to 2 lb. Increments |
| TGA160 | Dual Extension Chuck | 0-160 PSI to 5 lb. Increments |
| TGA300 | Dual Extension Chuck | 0-300 PSI to 10 lb. Increments |
| TG060 | Chuck Assembly | 0-60 PSI to 2 lb. Increments |
| TG160 | Chuck Assembly | 0-160 PSI to 5 lb. Increments |
| TG300 | Chuck Assembly | 0-300 PSI to 10 lb. Increments |
Dual Extension Chuck features chrome-plated extension chuck that swivels a full 360°.
Chuck Assembly features 7″ flexible black hose with swivel brass chuck.
** These gauges are dial type but can hold a reading after the chuck has been removed from the tire.
