| Overview: | |||
|---|---|---|---|
| |||
| Features: | |||
|
| Part No. | Material | Hose ID | Hose Length | End Type |
|---|---|---|---|---|
| RP0403 | Neoprene | 1/4″ | 3″ | 1/4 MPT Rigid x 1/4 FPT Ball Swivel |
| RP0406 | Neoprene | 1/4″ | 6″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0406S | Neoprene | 1/4″ | 6″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| PP0406S | Polyurethane | 1/4″ | 6″ | 1/4″ MPT Swivel x 1/4″ MPT Swivel |
| RP0412 | Neoprene | 1/4″ | 12″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| VP0412 | Thermoplastic | 1/4″ | 12″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0412S | Neoprene | 1/4″ | 12″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| VP0412S | Thermoplastic | 1/4″ | 12″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| PP0412S | Polyurethane | 1/4″ | 12″ | 1/4″ MPT Swivel x 1/4″ MPT Swivel |
| RP0418 | Neoprene | 1/4″ | 18″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| VP0418 | Thermoplastic | 1/4″ | 18″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0418S | Neoprene | 1/4″ | 18″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| VP0418S | Thermoplastic | 1/4″ | 18″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| PP0418S | Polyurethane | 1/4″ | 18″ | 1/4″ MPT Swivel x 1/4″ MPT Swivel |
| RP0424 | Neoprene | 1/4″ | 24″ | 1/4″ MPT x 1/4″ FPT Ball Swivel |
| VP0424 | Thermoplastic | 1/4″ | 24″ | 1/4″ MPT x 1/4″ FPT Ball Swivel |
| RP0424S | Neoprene | 1/4″ | 24″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| VP0424S | Thermoplastic | 1/4″ | 24″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| PP0424S | Polyurethane | 1/4″ | 24″ | 1/4″ MPT Swivel x 1/4″ MPT Swivel |
| RP0436 | Neoprene | 1/4″ | 36″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| VP0436 | Thermoplastic | 1/4″ | 36″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0436S | Neoprene | 1/4″ | 36″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| VP0436S | Thermoplastic | 1/4″ | 36″ | 1/4″ MPT Swivel x 1/4″ FPT Rigid |
| PP0436S | Polyurethane | 1/4″ | 36″ | 1/4″ MPT Swivel x 1/4″ MPT Swivel |
| Â | ||||
| RP0512 | Neoprene | 5/16″ | 12″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0518 | Neoprene | 5/16″ | 18″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0524 | Neoprene | 5/16″ | 24″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| RP0536 | Neoprene | 5/16″ | 36″ | 1/4″ MPT Rigid x 1/4″ FPT Ball Swivel |
| Â | ||||
| RP0612 | Neoprene | 3/8″ | 12″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| VP0612 | Thermoplastic | 3/8″ | 12″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| RP0612S | Neoprene | 3/8″ | 12″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| VP0612S | Thermoplastic | 3/8″ | 12″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| PP0612S | Polyurethane | 3/8″ | 12″ | 1/4″ MPT Swivel x 1/4″ MPT Swivel |
| RP0618 | Neoprene | 3/8″ | 18″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| VP0618 | Thermoplastic | 3/8″ | 18″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| RP0618S | Neoprene | 3/8″ | 18″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| VP0618S | Thermoplastic | 3/8″ | 18″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| PP0618S | Polyurethane | 3/8″ | 18″ | 3/8″ MPT Swivel x 3/8″ MPT Swivel |
| RP0624 | Neoprene | 3/8″ | 24″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| VP0624 | Thermoplastic | 3/8″ | 24″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| RP0624S | Neoprene | 3/8″ | 24″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| VP0624S | Thermoplastic | 3/8″ | 24″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| PP0624S | Polyurethane | 3/8″ | 24″ | 3/8″ MPT Swivel x 3/8″ MPT Swivel |
| RP0636 | Neoprene | 3/8″ | 24″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| VP0636 | Thermoplastic | 3/8″ | 24″ | 3/8″ MPT Rigid x 3/8″ FPT Ball Swivel |
| RP0636S | Neoprene | 3/8″ | 36″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| VP0636S | Thermoplastic | 3/8″ | 36″ | 3/8″ MPT Swivel x 3/8″ FPT Rigid |
| PP0636S | Polyurethane | 3/8″ | 36″ | 3/8″ MPT Swivel x 3/8″ MPT Swivel |
| Â | ||||
| RP0812 | Neoprene | 1/2″ | 12″ | 1/2″ MPT Rigid x 1/2″ FPT Ball Swivel |
| RP0818 | Neoprene | 1/2″ | 18″ | 1/2″ MPT Rigid x 1/2″ FPT Ball Swivel |
| RP0824 | Neoprene | 1/2″ | 24″ | 1/2″ MPT Rigid x 1/2″ FPT Ball Swivel |
| RP0836 | Neoprene | 1/2″ | 36″ | 1/2″ MPT Rigid x 1/2″ FPT Ball Swivel |
| Â | ||||
| RP1212 | Neoprene | 3/4″ | 12″ | 3/4″ MPT Rigid x 3/4″ FPT Ball Swivel |
| RP1218 | Neoprene | 3/4″ | 18″ | 3/4″ MPT Rigid x 3/4″ FPT Ball Swivel |
| RP1224 | Neoprene | 3/4″ | 24″ | 3/4″ MPT Rigid x 3/4″ FPT Ball Swivel |
| RP1236 | Neoprene | 3/4″ | 36″ | 3/4″ MPT Rigid x 3/4″ FPT Ball Swivel |
