| Overview: | |||
|---|---|---|---|
| |||
| Features: | |||
|
| Temperature Range: | -40° F to 165° F | Vacuum Rating: | To 28″ Hg. |
|---|---|---|---|
| Diameter Tolerances: | 1/8″ – 9/16″ +/- .005″ 3/4″ +/- .007″ | Working Pressure: | 3 to 1 Safety Factor |
| Compliance: | NSF61, Meets UL94HB | UV Stabilized: | Yes |
| Material: | 95A Polyurethane | Â | Â |
| Part Number 50ft Length | Part Number 500ft Length | Color | O.D. x I.D. | Wall Thickness | WorkingPressure at 75° F |
|---|---|---|---|---|---|
| PT1017-50K | PT1017-500K | Black | 10.0mm x 6.5mm | 1.75mm | 170 PSI |
| PT1017-50Y | PT1017-500Y | Yellow | |||
| PT1017-50TC | PT1017-500TC | Transparent Clear | |||
| PT1017-50TB | PT1017-500TB | Transparent Blue | |||
| PT1017-50R | PT1017-500R | Red | |||
| PT1017-50G | PT1017-500G | Green | |||
| PT1017-50B | PT1017-500B | Blue |
