SPECIFICATIONS
| Application: | Transfer of air, water and mild water soluble chemicals, Ideal for in-plant and outdoor applications that require an economical general purpose hose, Excellent air supply line for pneumatic tools and paint spray systems. | SAE Rating: | N/A |
|---|---|---|---|
| Other Ratings: | N/A | Tube: | Black PVC compound |
| Reinforcement: | High tensile strength yarn | Cover: | PVC compound |
| Temperature Range: | -15 deg. F (-26 deg. C) to +150 deg. F (+65 deg. C) | Crimp Fittings: | N/A |
| Reusable Fittings: | N/A | Specifications | N/A |
| Other Features: | |||
| |||
| Part Number | Nominal ID | Nominal OD | Working Pressure | Standard Lengths | Approx Weight per Pkg | |||
|---|---|---|---|---|---|---|---|---|
| (in.) | (mm) | (in.) | (mm) | @ 70 deg. F (20 deg. C) (PSI) | @ 122 deg. F (50 deg. C) (PSI) | Coils | ||
| K1171-04X500 | 1/4″ | 6.5mm | .475″ | 12.1mm | 300 PSI | 150 PSI | 500 ft. | 36 lbs. |
| K1171-06X500 | 3/8″ | 9.5mm | .600″ | 15.2mm | 300 PSI | 150 PSI | 500 ft. | 48 lbs. |
| K1171-08X300 | 1/2″ | 12.7 mm | .750″ | 19.1mm | 300 PSI | 150 PSI | 300 ft. | 42 lbs. |
Note: Working Pressure decreases as temperature increases. Pressure ratings can only be obtained with proper coupling procedures.
