SPECIFICATIONS
| Application: | Pest control spraying, Agricultural spraying, Commercial weed spraying | SAE Rating: | N/A |
|---|---|---|---|
| Other Ratings: | N/A | Tube: | Black PVC/polyurethane blend |
| Reinforcement: | High tensile strength yarn. | Cover: | Ribbed PVC. |
| Temperature Range: | +15 deg. F (-10 deg. C) to +160 deg. F (+70 deg. C) | Crimp Fittings: | N/A |
| Reusable Fittings: | N/A | Specifications | N/A |
| Other Features: | |||
| |||
| Part Number | Nominal ID | Nominal OD | Max. Working Pressure | Standard Lengths | Approx Weight per Pkg | |||
|---|---|---|---|---|---|---|---|---|
| (in.) | (mm) | (in.) | (mm) | @ 70 deg. F (20 deg. C) (PSI) | @ 122 deg. F (50 deg. C) (PSI) | Coil | ||
| A1628-06X300 | 3/8″ | 9.5mm | .625″ | 15.9mm | 300 PSI | 150 PSI | 300 ft | 36 lbs. |
| A1628-06X400 | 3/8″ | 9.5mm | .625″ | 15.9mm | 300 PSI | 150 PSI | 400 ft | 47 lbs. |
| A1628-08X300 | 1/2″ | 12.7mm | .770″ | 19.6mm | 300 PSI | 150 PSI | 300 ft | 49 lbs. |
| A1628-08X400 | 1/2″ | 12.7mm | .770″ | 19.6mm | 300 PSI | 150 PSI | 400 ft | 65 lbs. |
| A1628-12X300 | 3/4″ | 19.1mm | 1.060″ | 26.9mm | 200 PSI | 100 PSI | 300 ft | 80 lbs. |
| A1628-16X200 | 1″ | 25.4mm | 1.306″ | 33.2mm | 200 PSI | 100 PSI | 200 ft | 67 lbs. |
Note: Working Pressure decreases as temperature increases. Pressure ratings can only be obtained with proper coupling procedures.
Note: Use of hydraulic or reusable-type fittings are not recommended for coupling Kuri TecĀ® hose products. Hose claims involving use of these
fittings will be disallowed.
