| Features: | |||
|---|---|---|---|
| |||
| Construction: | |||
| |||
| Specifications: | |||
| |||
| About Midland Press Ball Valves: | |||
|
| Part Name | Material |
|---|---|
| Body | Lead Free Brass |
| Seat | PTFE |
| Ball | Stainless Steel |
| Stem O-Ring | NBR |
| Packing Nut | Brass |
| Stem | Brass (1/2″ – 2″) Stainless Steel(2-1/2″ – 4″) |
| Lock Nut | Ferrum /Zinc Plated |
| Lock Washer | Ferrum /Zinc Plated |
| Packing | PTFE |
| Handle | Ferrum /Chrome Plated |
| Cap | Lead Free Brass |
| Body O-Ring | NBR |
| Press O-Ring | EPDM |
![]() |
||||||
|---|---|---|---|---|---|---|
| Part Number | Size | D | L | H | W | CV |
| 940403LF | 1/2″ | 0.591″ | 3.46″ | 1.81″ | 3.15″ | 18.55 |
| 940404LF | 3/4″ | 0.748″ | 4.29″ | 2.09″ | 3.60″ | 29.76 |
| 940405LF | 1″ | 0.984″ | 4.29″ | 2.25″ | 3.92″ | 51.55 |
| 940406LF | 1-1/4″ | 1.259″ | 5.63″ | 2.52″ | 4.41″ | 84.42 |
| 940407LF | 1-1/2″ | 1.574″ | 5.63″ | 2.74″ | 5.35″ | 131.93 |
| 940408LF | 2″ | 1.941″ | 5.63″ | 3.03″ | 6.79″ | 200.35 |
| 940409LF | 2-1/2″ | 2.520″ | 7.76″ | 4.25″ | 7.46″ | 338.43 |
| 940410LF | 3″ | 2.874″ | 8.19″ | 4.58″ | 8.17″ | 445.44 |
| 940411LF | 4″ | 3.839″ | 9.25″ | 5.49″ | 9.88″ | 783.88 |
