| Overview: | |||
|---|---|---|---|
| |||
| Features: | |||
| |||
| Warning: | |||
|
| Maximum Supply Pressure: | Plastic Bowl:150 PSI Metal Bowl:250 PSI | Materials: | Plastic Bowl: Polycarbonate Metal Bowl: Die Cast Aluminum Body: Die Cast Aluminum |
|---|
| Size | Height | Diameter | Bowl Capacity | Weight |
|---|---|---|---|---|
| 1/4″ & 3/8″ | 7″ | 3″ | 4 oz. | 1 lbs. |
| 1/2″ | 8″ | 3-1/2″ | 8 oz. | 1-1/4 lbs. |
| 3/4″ & 1″ | 11-1/2″ | 5″ | 23 oz. | 3-1/2 lbs. |
| Supply 100 PSI Regulated Pressure | Pressure Drop | ||
|---|---|---|---|
| 5 | 10 | 15 | |
| 1/4″ at 80 PSI | 27.5 SCFM | 39 SCFM | 48 SCFM |
| 3/8″ at 80 PSI | 27.5 SCFM | 39 SCFM | 48 SCFM |
| 1/2″ at 80 PSI | 55 SCFM | 79 SCFM | 97 SCFM |
| 3/4″ at 80 PSI | 110 SCFM | 158 SCFM | 195 SCFM |
| 1″ at 80 PSI | 110 SCFM | 158 SCFM | 195 SCFM |
| Note: All values are approximate. | |||
| Model | Pipe Size | Material | Max Pressure |
|---|---|---|---|
| 8842 | 1/4″ | Polycarbonate | 150 PSI |
| 8842-CS* | 1/4″ | Polycarbonate | 150 PSI |
| 8842M | 1/4″ | Metal | 250 PSI |
| 8842R | 1/4″ | Polycarbonate with Bowl Guard | 150 PSI |
| Â | |||
| 8843 | 3/8″ | Polycarbonate | 150 PSI |
| 8843-CS* | 3/8″ | Polycarbonate | 150 PSI |
| 8843M | 3/8″ | Metal | 250 PSI |
| 8843R | 3/8″ | Polycarbonate with Bowl Guard | 150 PSI |
| Â | |||
| 8844 | 1/2″ | Polycarbonate | 150 PSI |
| 8844R | 1/2″ | Polycarbonate with Bowl Guard | 150 PSI |
| 8844M | 1/2″ | Metal | 250 PSI |
| Â | |||
| 8846 | 3/4″ | Polycarbonate with Bowl Guard | 150 PSI |
| 8846M | 3/4″ | Metal | 250 PSI |
| Â | |||
| 8848 | 1″ | Polycarbonate with Bowl Guard | 150 PSI |
| 8848M | 1″ | Metal | 250 PSI |
* Clamshell Packaging
