| Technical Characteristics: |
|
|---|---|
| Advantages: | Productivity: Higher maximum flow than standard regulators Optimal control of the cylinder rod speed Accuracy: Precise adjustment for accurate flow regulation Long-term stability of flow Ergonomics: External adjustment screw: easy to adjust ; Recessed adjustment screw: protects the adjustment mechanism Can be rotated 360° during assembly |
| Regulations: |
|
| Component Materials: |
|
![]() |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Part Number | ØD | F | G | H (max) | H (min) | H1 | H2 | L | Kg |
| 7030 06 00 | 6 mm | 10 mm | 16 mm | 41 mm | 35 mm | 14 mm | 17 mm | 22 mm | .013 Kg |
| 7030 08 00 | 8 mm | 14 mm | 19 mm | 46.5 mm | 39.5 mm | 16 mm | 21.5 mm | 28 mm | .022 Kg |
| 7030 12 00 | 12 mm | 17 mm | 23 mm | 51 mm | 43 mm | 17 mm | 27 mm | 35 mm | .044 Kg |
