| Product Features: |
|
|---|---|
| Markets: |
|
| Applications: |
|
| Specification: | |
| Pressure Range: | Up to 150 PSI (10.3 bar) |
| Temperature Range: | 0° to +150° F (-17.7° to +65.5° C) |
| O-Rings: | Buna N on chrome plated couplers Fluorocarbon on Stainless Steel couplers |
| Compatible Tubing: |
|
![]() |
|||||||
|---|---|---|---|---|---|---|---|
| Part Number | Tube Size | Pipe Thread | Straight Thread | Hex (C) | L | M | Flow Diameter (D) |
| 66P-4-2 | 1/4″ | 1/8″ | 3/8″-24 | 9/16″ | .97″ | .86″ | .125″ |
| 66P-4-4 | 1/4″ | 1/4″ | 3/8″-24 | 5/8″ | 1.18″ | 1.07″ | .125″ |
| 66P-5-2 | 5/16″ | 1/8″ | 7/16″-24 | 9/16″ | .97″ | .86″ | .144″ |
| 66P-6-4 | 3/8″ | 1/4″ | 1/2″-24 | 5/8″ | 1.18″ | 1.07″ | .204″ |
| 66P-8-6 | 1/2″ | 3/8″ | 11/16″-20 | 13/16″ | 1.31″ | 1.20″ | .323″ |
