5500RK1 By Dixon Valve | 5500-Series | Complete Repair Kit For 5500B 4″ API Coupler | FKM-B Seal

Original price was: $58.20.Current price is: $40.74.

SKU: AG9ZZ 8799457181861 Categories: Additional Equipment, Tools & Equipment Tags: All-categories, Collection-lvl1_All Hose Accessories, Collection-lvl2_Replacement Parts, Collection-lvl3_Repair Parts and Kits, Created in 2024, Dixon Valve and Coupling Products, Engineered Fluid Transfer Couplings, Industrial Hose Fittings, LegacyProductTypeReplacement_All Categories, Matrixify1st50kProducts, Replacement Parts, Swivels & Rack Equipment

100% Quality Satisfaction
Friendly, efficient service, always online.
7 days free returns
Safe Payments, Happy Customers

Description
Reviews (0)

Features:
Locking five-cam design provides easy alignment and tight connection. Modular design allows various face seal combinations to be compatible with different alternative fuels, performance levels, and applications. Shaft seals can be changed without removing coupler from the loading arm. Fully interlocked collar cannot be opened when connected and cannot be disconnected when opened. Replaceable seal design while coupler is on loading arm. 4″ TTMA inlet mounting flange connection. Ball-end handle for easy and comfortable operation. No special tools needed for maintenance.
Materials:
Body: hard coated anodized 356T6 aluminum. Shroud: hard coated anodized 356T6 aluminum with stainless steel insert. Link, shaft, pin, and crank: hardened 17-4PH stainless steel. Cam: CF8M stainless steel. Poppet and bearing: Bayloy. Seals: Baylast™, EPDM, FFKM, FKM-B, FKM-GFLT, fluorosilicone, and Hifluor.
Specifications:
Seal operating temperature: Baylast: -20°F to 250°F (-28°C to 121°C) EPDM: -40°F to 250°F (-40°C to 120°C) FKM-B: -10°F to 400°F (-23°C to 204°C) FKM-GFLT: -20°F to 400°F (-28°C to 204°C) Fluorosilicone: -50°F to 300°F (-40°C to 149°C) Hifluor: 23°F to 350°F (-5°C to 176°C) Flow rate: 600 GPM at 3 PSI pressure drop, maximum flow rate: 1,000 GPM. Fully compliant with API RP1004:2003 specifications. Burst tested: 450 PSI.
Notes:
Complete repair kit contains all the seals, pins, and cotter keys to replace all the seals.

Part Number	Description	Seal Material	Complete Repair Kit	Replaceable Nose Seal
5500BL	4″ API Coupler	Baylast	5500RK2	5500RK8
5500E	4″ API Coupler	EPDM	5500RK3	5500RK9
5500B	4″ API Coupler	FKM-B	5500RK1	5500RK7
5500G	4″ API Coupler	FKM-GFLT	5500RK5	5500RK11
5500F	4″ API Coupler	Fluorosilicone	5500RK4	5500RK10
–	4″ API Coupler	Hifluor	5500RK19	5500RK20

5500-Series \| API Coupler Repair Kits
Part	Description
5500RK21	Small Parts Kit For 5500 Series Rack Coupler
5500RK22	Aluminum Replacement Handle Kit With Bolt and Nut
5500RK23	Stainless Steel Replacement Handle Kit with Bolt and Nut
5500RK24	Locking Handle Kit
5500RK25	Aluminum Short Handle Replacement Kit with Bolt and Nut
5500RK26	Replacement Poppet Kit With Lins, Pins, and Cotter Pin
5500RK27	Replacement Seal Cylinder – No Seal
5500RK51	Replacement FKM-GFLT Bearing Kit for 5500
