50210N-8-3/8 By AIGNEP | 50N Series | Swivel Branch | 8mm Tube X 3/8" Swift-Fit Male | Tee | Pack Of 10

50210N-8-3/8 By AIGNEP | 50N Series | Swivel Branch | 8mm Tube X 3/8" Swift-Fit Male | Tee | Pack Of 10 - Image 2

50210N-8-3/8 By AIGNEP | 50N Series | Swivel Branch | 8mm Tube X 3/8″ Swift-Fit Male | Tee | Pack Of 10

Original price was: $41.60.Current price is: $29.12.

SKU: AG9ZZ 7711741706405 Categories: Fittings & Clamps, Tube Fittings Tags: 50N Series, 8mm Tube x 3/8" Swift-Fit Male, Collection-lvl1_All Hose Ends, Collection-lvl2_Ends for Special Hose Types, Collection-lvl3_Tube Fittings, JD052722-00, Matrixify2nd50kProducts, Swivel Branch Tee

100% Quality Satisfaction
Friendly, efficient service, always online.
7 days free returns
Safe Payments, Happy Customers

Description
Reviews (0)

Swivel Branch Tee

Pressure Rating: Vacuum-290 PSI
Temperature Range: 0-176° F
Tubing Compatibility: Nylon, Polyethylene, Polyurethane, Copper
Media: Compressed Air, Water
Body: Nickel Plated Brass
Thread Seal: NBR 70
Thread Type: SWIFTFIT

Tube	A	B (IN)	B	L1	L2
50210N-4-1/8	4 mm	1/8″	0.216″	5.5 mm	34 mm	20 mm
50210N-4-1/4	4 mm	1/4″	0.276″	7 mm	34 mm	21.5 mm
50210N-5-1/8	5 mm	1/8″	0.216″	5.5 mm	40 mm	22 mm
50210N-6-1/8	6 mm	1/8″	0.216″	5.5 mm	42 mm	22 mm
50210N-6-1/4	6 mm	1/4″	0.276″	7 mm	42 mm	23.5 mm
50210N-8-1/8	8 mm	1/8″	0.216″	5.5 mm	45 mm	25.5 mm
50210N-8-1/4	8 mm	1/4″	0.276″	7 mm	45 mm	25.5 mm
50210N-8-3/8	8 mm	3/8″	0.295″	7.5 mm	45 mm	26 mm
50210N-8-1/2	8 mm	1/2″	0.374″	9 mm	45 mm	28.5 mm
50210N-10-1/4	10 mm	1/4″	0.276″	7 mm	53 mm	29 mm
50210N-10-3/8	10 mm	3/8″	0.295″	7.5 mm	53 mm	27 mm
50210N-10-1/2	10 mm	1/2″	0.374″	9 mm	53 mm	29.5 mm
50210N-12-3/8	12 mm	3/8″	0.295″	7.5 mm	62.6 mm	29.5 mm
50210N-12-1/2	12 mm	1/2″	0.374″	9 mm	62.6 mm	32 mm
50210N-14-3/8	14 mm	3/8″	0.295″	7.5 mm	62.6 mm	29.5 mm
50210N-14-1/2	14 mm	1/2″	0.374″	9 mm	62.6 mm	32 mm
