Sale!
5/8″ R16 By Couplamatic | Import Two Wire Hi-Pressure Extremely Flexible Hydraulic Hose | SAE 100R16/DIN 2SC | 5/8″ ID | 250ft
Original price was: $310.00.$99.99Current price is: $99.99.
- 100% Quality Satisfaction
- Friendly, efficient service, always online.
- 7 days free returns
- Safe Payments, Happy Customers
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R16 / DIN 2SC |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Cover, MSHA Approved | Reinforcement: | Two Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) | Min. Burst Pressure (lbs) | Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4″ R16 | 1/4″ | 0.530″ | 5,800 lbs. | 23,200 lbs. | 2″ | 18 lbs. | 500ft |
| 3/8″ R16 | 3/8″ | 0.687″ | 5,000 lbs. | 20,000 lbs. | 2.5″ | 27 lbs. | 400ft |
| 1/2″ R16 | 1/2″ | 0.812″ | 4,250 lbs. | 17,000 lbs. | 3.5″ | 35 lbs. | 300ft |
| 5/8″ R16 | 5/8″ | 0.937″ | 3,625 lbs. | 14,500 lbs. | 4″ | 40 lbs. | 250ft |
| 3/4″ R16 | 3/4″ | 1.090″ | 3,125 lbs. | 12,500 lbs. | 4.8″ | 54 lbs. | 250ft |
| 1″ R16 | 1″ | 1.405″ | 2,500 lbs. | 10,000 lbs. | 6″ | 74 lbs. | 200ft |
**Crimps to 100R1AT One Wire Thin Cover Specifications – Tighter Bend Radius than R1 and R2**
