Sale!
3809 08 14 By Parker | Legris Stud Swivel Fitting | 8 Mm Tube Size X 1/4" Male NPT Thread | 14 Mm Hex | 90° Elbow | 316L Stainless Steel | Pack Of 2

3809 08 14 By Parker | Legris Stud Swivel Fitting | 8 Mm Tube Size X 1/4″ Male NPT Thread | 14 Mm Hex | 90° Elbow | 316L Stainless Steel | Pack Of 2

Original price was: $120.30.Current price is: $84.21.

SKU: AG9ZZ 14646571729266 Categories: , Tags: ,
  • 100% Quality Satisfaction
  • Friendly, efficient service, always online.
  • 7 days free returns
  • Safe Payments, Happy Customers
Technical Characteristics:
  • Compatible Fluids: All fluids compatible with the fitting component materials
  • Working Pressure: Vacuum to 30 bar. (20 bar: 3879 and 3889)
  • Working Temperature: -25°C to +150°C
Advantages:
  • Resistance to corrosion thanks to the component material
  • Suitable for permanent food contact
  • Suitable for industrial cleaning agents and detergents
  • Hygienic external design, for reducing retention zones
Regulations:
  • ISO 14743
  • RoHS
  • REACH
  • FDA: 21 CFR
  • PED
Component Materials:
  • Body: Stainless Steel 316L
  • Adapter: Stainless Steel 316L
  • Collet: Stainless Steel 316L
  • Protection Washer: Stainless Steel 316L
  • Seals: FKM
3809 08 14 By Parker | Legris Stud Swivel Fitting | 8 Mm Tube Size X 1/4" Male NPT Thread | 14 Mm Hex | 90° Elbow | 316L Stainless Steel | Pack Of 2 -Hose Ware House Screenshot 2024 09 18 083909
Part Number ØD C F G H L Kg
3809 06 11 6 mm 1/8″ 13 mm 12.5 mm 29 mm 22.5 mm .031 Kg
3809 06 14 8 mm 1/4″ 14 mm 12.5 mm 29 mm 22.5 mm .036 Kg
3809 08 11 8 mm 1/8″ 14 mm 15 mm 34 mm 24 mm .031 Kg
3809 08 14 8 mm 1/4″ 14 mm 15 mm 34 mm 24 mm .045 Kg
3809 10 14 10 mm 1/4″ 19 mm 17.5 mm 39.5 mm 30 mm .068 Kg
3809 10 18 10 mm 3/8″ 19 mm 17.5 mm 39.5 mm 30 mm .071 Kg

The body swivels for positioning purposes.
