Sale!
32082 By Midland | Hose Barb Flare | 1/4″ Hose ID X 3/8″ Male 45° Flare | 45° Elbow | Adapter | Brass
Original price was: $12.00.$8.40Current price is: $8.40.
- 100% Quality Satisfaction
- Friendly, efficient service, always online.
- 7 days free returns
- Safe Payments, Happy Customers
SPECIFICATIONS
| Applications: | N/A | Used With: | These fittings are intended for use with hose clamp, similar type clamp or a crimped ferrule. |
|---|---|---|---|
| SAE Rating: | N/A | Conformance: | N/A |
| Vibration: | N/A | Temperature Range: | -40°F to +160°F at 150 PSI maximum. |
| Tolerance: |
+/- .02 on all dimensions. Dimension Data can change without notice. Please call us when dimensions are critical. |
Lead Free: | N/A |
| Assembly Instructions: |
1. Cut hose cleanly and squarely to length. 2. Slide clamp on hose. 3. Lubricate hose. Push hose on fitting until hose bottoms against stop ring or hex. 4. Position hose clamp as shown below and secure with a screwdriver or wrench. Maintain “A” dimension noted below for proper clamp positioning. |
||
| Hose Size | 3/16″ | 1/4″ | 5/16″ | 3/8″ | 1/2″ | 5/8″ | 3/4″ |
|---|---|---|---|---|---|---|---|
| A | 1/4″ | 1/4″ | 1/4″ | 1/8″ | 1/8″ | 1/8″ | 1/8″ |
| Crossover Series: | |||||
|---|---|---|---|---|---|
| 29SAE | 129SAE | 142 | 201BF | KF-MS | KDS |
 |
||||||
|---|---|---|---|---|---|---|
| Part Number | Hose I.D. x Male 45° Flare | Thread | A | B | Hex | Approx. Weight (Lbs.) |
| 32322 (32-322) |
3/16″ x 1/4″ | 7/16-20 | 1.50″ | 0.75″ | 0.43″ | 0.03 |
| 32081 (32-081) |
1/4″ x 1/4″ | 7/16-20 | 1.72″ | 0.97″ | 0.43″ | 0.03 |
| 32082 (32-082) |
1/4″ x 3/8″ | 5/8-18 | 1.82″ | 0.97″ | 0.62″ | 0.07 |
| 32083 (32-083) |
5/16″ x 5/16″ | 1/2-20 | 1.75″ | 0.97″ | 0.50″ | 0.08 |
| 32084 (32-084) |
3/8″ x 3/8″ | 5/8-18 | 1.82″ | 0.97″ | 0.62″ | 0.08 |
| 32085 (32-085) |
3/8″ x 1/2″ | 3/4-16 | 1.97″ | 0.97″ | 0.75″ | 0.10 |
| 32086 (32-086) |
1/2″ x 1/2″ | 3/4-16 | 1.97″ | 0.97″ | 0.75″ | 0.10 |
