3108 53 10 By Parker | LF3000® Push-to-Connect Fittings | 1/8″ Push-to-Connect X 1/8″ Push-to-Connect X 1/8″ Male BSPT Thread | 10 Mm Hex | 1.10″ Length | Tee | Polymer | Pack Of 10
Original price was: $112.79.$78.95Current price is: $78.95.
- 100% Quality Satisfaction
- Friendly, efficient service, always online.
- 7 days free returns
- Safe Payments, Happy Customers
| Technical Characteristics: |
|
|---|---|
| Advantages: |
|
| Regulations: |
|
| Component Materials: |
|
 |
|||||||
|---|---|---|---|---|---|---|---|
| Part Number | ØD | C | F | G | H | L/2 | Kg |
| 3108 53 10 | 1/8″ | 1/8″ | 10 mm | .34″ | .61″ | .55″ | .0059 Kg |
| 3108 04 10 | 4 mm | 1/8″ | 10 mm | 8.5 mm | 15.5 mm | 14 mm | .006 Kg |
| 3108 04 13 | 4 mm | 1/4″ | 14 mm | 8.5 mm | 16 mm | 14 mm | .015 Kg |
| 3108 55 10 | 3/16″ | 1/8″ | 11 mm | .43″ | .67″ | .85″ | .0398 Kg |
| 3108 55 13 | 3/16″ | 1/4″ | 14 mm | .43″ | .67″ | .85″ | .0309 Kg |
| 3108 56 10 | 1/4″ | 1/8″ | 10 mm | .43″ | .67″ | .71″ | .0506 Kg |
| 3108 56 13 | 1/4″ | 1/4″ | 14 mm | .43″ | .63″ | .71″ | ..575 Kg |
| 3108 06 10 | 6 mm | 1/8″ | 10 mm | 10.5 mm | 17.5 mm | 16 mm | .007 Kg |
| 3108 06 13 | 6 mm | 1/4″ | 14 mm | 10.5 mm | 18 mm | 16 mm | .016 Kg |
| 3108 08 10 | 8 mm | 1/8″ | 10 mm | 13.5 mm | 22 mm | 23 mm | .009 Kg |
| 3108 08 13 | 8 mm | 1/4″ | 14 mm | 13.5 mm | 21 mm | 23 mm | .016 Kg |
| 3108 08 17 | 8 mm | 3/8″ | 17 mm | 13.5 mm | 21 mm | 23 mm | .020 Kg |
| 3108 60 13 | 3/8″ | 3/4″ | 15 mm | .63″ | .95″ | 1.04″ | .068 Kg |
| 3108 60 17 | 3/8″ | 3/8″ | 17 mm | .63″ | .95″ | 1.04″ | .068 Kg |
| 3108 60 21 | 3/8″ | 1/2″ | – | – | – | – | – |
| 3108 10 13 | 10 mm | 1/4″ | 15 mm | 16 mm | 24 mm | 26.5 mm | .017 Kg |
| 3108 10 17 | 10 mm | 3/8″ | 17 mm | 16 mm | 24 mm | 26.5 mm | .022 Kg |
| 3108 10 21 | 10 mm | 1/2″ | 21 mm | 16 mm | 24 mm | 26.5 mm | .034 Kg |
| 3108 62 21 | 1/2″ | 1/2″ | – | – | – | – | – |
| 3108 12 13 | 12 mm | 1/4″ | 19 mm | 27 mm | 31 mm | 021 mm | .021 Kg |
| 3108 12 17 | 12 mm | 3/8″ | 17 mm | 19 mm | 27 mm | 31 mm | .027 Kg |
| 3108 12 21 | 12 mm | 1/2″ | 21 mm | 19 mm | 27 mm | 31 mm | .041 Kg |
| 3108 14 17 | 14 mm | 3/8″ | 20 mm | 22 mm | 30.5 mm | 35 mm | .038 Kg |
| 3108 14 21 | 14 mm | 1/2″ | 24 mm | 22 mm | 28.5 mm | 35 mm | .049 Kg |
| 3108 16 17 | 16 mm | 3/8″ | 27 mm | 27 mm | 53 mm | 38.5 mm | .128 Kg |
| 3108 16 21 | 16 mm | 1/2″ | 27 mm | 27 mm | 53 mm | 38.5 mm | .124 Kg |
Pre-coated thread
The body swivels for positioning purposes.
