SPECIFICATIONS
| Application: | Used in the delivery of biofuels, gasoline, kerosene and fuel oil | SAE Rating: | N/A |
|---|---|---|---|
| Other Ratings: | N/A | Tube: | Polyurethane, Smooth Bore |
| Reinforcement: | Embedded SĪ© Ground Wire, Clockwise PVC helix, Single Braid, High Tensile Polyester Yarn | Cover: | N/A |
| Temperature Range: | -40 deg. F (-40 deg. C) to +140 deg. F (+60 deg. C) | Crimp Fittings: | N/A |
| Reusable Fittings: | N/A | Branding: | N/A |
| Other Features: | |||
| |||
| Part Number | I.D. | O.D. | Reinforcement Braids | Max. Working Press. @ 68 deg. F | Vacuum @ 68 deg. F | Weight | Min. Bend Radius | Standard Length | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in. | mm | in. | mm | PSI | BAR | inHg | lb./ft. | KG/m | in. | mm | ft | ||
| Uncoupled | |||||||||||||
| 3045-0300-100 | 3″ | 76.20mm | 3.78″ | 96.01mm | 1 | 65 PSI | 4.48 BAR | 29.0 inHg | 1.20 lb./ft. | 1.79 KG/m | 6.00″ | 152.40mm | 100ft |
| 3045-0400-100 | 4″ | 101.60mm | 4.83″ | 122.68mm | 1 | 65 PSI | 4.48 BAR | 29.0 inHg | 1.71 lb./ft. | 2.54 KG/m | 8.00″ | 203.20mm | 100ft |
Note: Use JASON YELLOW banding sleeves only when securing coupling for 2″, 3″ and 4″ ID’s.
Discharge pressures and vacuum are temperature dependent.
SĪ© = Safety Ohm
Working pressure is temperature dependent.
Jason Industrial Inc. disclaims any liability for use of their products in applications other than which they are designed.
