SPECIFICATIONS
| Applications: | Low Pressure Air, Fuel, Lube, and Oil Lines Pressure determined by tube material and hardness. Midland Parts have been tested to max 150 PSI |
Advantages: | Easy assembly. No clamps needed. |
|---|---|---|---|
| SAE Rating: | N/A | Lead Free: | No |
| Assembly Instructions: | |||
|---|---|---|---|
|
|||
| Disassembling Instructions: | |||
|
![]() |
|---|
| Crossover Series: | ||||||
|---|---|---|---|---|---|---|
| 29P016 | 129PO6 | 290 | 100B-B | KA-MF | 1MS | 947 |
![]() |
||||||
|---|---|---|---|---|---|---|
| Part Number | Hose ID x Male Inverted Flare | UNF Thread | A | B | Hex | Approx. Weight (Lbs.) |
| 30275 (30-275) |
1/4″ x 3/16″ | 3/8-24 | 1.52″ | 0.87″ | 0.37″ | 0.04 |
| 30276 (30-276) |
1/4″ x 1/4″ | 7/16-24 | 1.56″ | 0.87″ | 0.43″ | 0.04 |
| 30277 (30-277) |
1/4″ x 5/16″ | 1/2-20 | 1.62″ | 0.87″ | 0.50″ | 0.04 |
| 30280 (30-280) |
5/16″ x 5/16″ | 1/2-20 | 1.62″ | 0.87″ | 0.50″ | 0.06 |
| 30283 (30-283) |
5/16″ x 3/8″ | 5/8-18 | 1.63″ | 0.87″ | 0.62″ | 0.06 |
| 30284 (30-284) |
3/8″ x 5/16″ | 1/2-20 | 1.72″ | 0.97″ | 0.50″ | 0.06 |
| 30279 (30-279) |
3/8″ x 3/8″ | 5/8-18 | 1.76″ | 0.97″ | 0.62″ | 0.06 |
| 30282 (30-282) |
1/2″ x 1/2″ | 3/4-18 | 1.84″ | 0.97″ | 0.75″ | 0.10 |
| 30286 (30-286) |
5/8″ x 5/8″ | 7/8-18 | 2.50″ | 1.57″ | 0.87″ | 0.14 |
