SPECIFICATIONS
| Application: | Dust collection, dry fertilizer, plastic pellets or any dry medium abrasive requirements. | SAE Rating: | N/A |
|---|---|---|---|
| Other Ratings: | N/A | Tube: | Medium Duty Abrasion Resistant Polyurethane Liner |
| Reinforcement: | Clockwise PVC Helix | Cover: | Static Dissipating PVC |
| Temperature Range: | -40 deg. F (-40 deg. C) to +140 deg. F (+60 deg. C) | Crimp Fittings: | N/A |
| Reusable Fittings: | N/A | Branding: | N/A |
| Other Features: | |||
| |||
| Part Number | I.D. | O.D. | Reinforcement | Max. Working Press. @ 68 deg. F | Vacuum @ 68 deg. F | Weight | Min. Bend Radius | Standard Length | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in. | mm | in. | mm | PSI | BAR | inHg | lb./ft. | KG/m | in. | mm | ft | ||
| Uncoupled | |||||||||||||
| 3022-0150-100 | 1-1/2″ | 38.10mm | 1.91″ | 48.51mm | PVC Helix | 30 PSI | 2.07 BAR | 24.0 inHg | 0.29 lb./ft. | 0.43 KG/m | 1.37″ | 34.80mm | 100ft |
| 3022-0200-100 | 2″ | 50.80mm | 2.46″ | 62.48mm | PVC Helix | 25 PSI | 1.72 BAR | 22.0 inHg | 0.40 lb./ft. | 0.60 KG/m | 2.50″ | 63.50mm | 100ft |
| 3022-0250-100 | 2-1/2″ | 63.50mm | 2.90″ | 73.66mm | PVC Helix | 20 PSI | 1.38 BAR | 19.0 inHg | 0.54 lb./ft. | 0.80 KG/m | 2.50″ | 63.50mm | 100ft |
| 3022-0300-100 | 3″ | 76.20mm | 3.53″ | 89.66mm | PVC Helix | 20 PSI | 1.38 BAR | 18.0 inHg | 0.68 lb./ft. | 1.01 KG/m | 4.00″ | 101.60mm | 100ft |
| 3022-0400-100 | 4″ | 101.60mm | 4.57″ | 116.08mm | PVC Helix | 15 PSI | 1.03 BAR | 13.0 inHg | 1.01 lb./ft. | 1.50 KG/m | 6.00″ | 152.40mm | 100ft |
Working pressure is temperature dependent.
Jason Industrial Inc. disclaims any liability for use of their products in applications other than which they are designed.
