SPECIFICATIONS
| Applications: | Carpet Cleaning, Marine Sanitation, Pumper, Sewer & Waste | SAE Rating: | N/A |
|---|---|---|---|
| Other Ratings: | N/A | Tube: | Polyethylene copolymer |
| Reinforcement: | Integral polyethylene helix | Cover: | N/A |
| Temperature Range: | -40 deg. F to 160 deg. F | Crimp Fittings: | N/A |
| Reusable Fittings: | N/A | ||
| Other Features: | |||
| |||
| Part Number 25 ft Reels | Part Number 50 ft Reels | Inside Diameter | Wall Thickness (In) | Centerline Bend Radius (In) | Compression Ratio | Negative Pressure (In/Hg) | Working Pressure (PSI) | Weight – 25ft (Lbs/Ft) | Weight – 50ft (Lbs/Ft) |
|---|---|---|---|---|---|---|---|---|---|
| STM 1.5in | STM 1.5in | 1.5″ | N/A | 2.75″ | N/A | 29 | 16 | 7.25 lbs | 14.5 lbs |
| STM 2in | STM 2in | 2″ | N/A | 4.25″ | N/A | 29 | 15 | 11 lbs | 22 lbs |
Technical data based on 2 ft. straight lengths of hose @ 72 deg.
