Sale!
01VL07OC03N By AIGNEP | 01V Series | Pneumatic Valve | 5/3 Lever/Spring Centered Open Center | 1/4″ NPTF Ports
Original price was: $47.44.$33.21Current price is: $33.21.
- 100% Quality Satisfaction
- Friendly, efficient service, always online.
- 7 days free returns
- Safe Payments, Happy Customers
90° LEVER VALVE
Technical Characteristics:
Operating Rating:
0 ÷ 10 bar
0 ÷ 145 psi
Pressure Drive:
Monostable: 2 ÷ 10 bar / 29 ÷ 145 psi
Bistable: 1 ÷ 10 bar / 14.5 ÷ 145 psi
Temperature:
Min: 14°F (-10°C)
Max: 140°F (60°C)
Component Parts and Materials:
• Anodised and painted aluminium body
• Chemical nickel-plated spool
• NBR seals
| Part Number | Ways | Reactuation | Function | Size |
|---|---|---|---|---|
| 01VL03NC02N | 3/2 | Lever Operated – Spring Return | Normally Closed (NC) | 1/8 NPTF |
| 01VL03NC03N | 3/2 | Lever Operated – Spring Return | Normally Closed (NC) | 1/4 NPTF |
| 01VL130002N | 3/2 | Lever Operated – Push/Pull | – | 1/8 NPTF |
| 01VL130003N | 3/2 | Lever Operated – Push/Pull | – | 1/4 NPTF |
| 01VL050002N | 5/2 | Lever Operated – Spring Return | – | 1/8 NPTF |
| 01VL050003N | 5/2 | Lever Operated – Spring Return | – | 1/4 NPTF |
| 01VL150002N | 5/2 | Lever Operated – Push/Pull | – | 1/8 NPTF |
| 01VL150003N | 5/2 | Lever Operated – Push/Pull | – | 1/4 NPTF |
| 01VL07CC02N | 5/3 | Lever Operated – Spring Centered | Center Closed (CC) | 1/8 NPTF |
| 01VL07CC03N | 5/3 | Lever Operated – Spring Centered | Center Closed (CC) | 1/4 NPTF |
| 01VL07OC02N | 5/3 | Lever Operated – Spring Centered | Opened Center (OC) | 1/8 NPTF |
| 01VL07OC03N | 5/3 | Lever Operated – Spring Centered | Opened Center (OC) | 1/4 NPTF |
| 01VL27CC02N | 5/3 | Lever Operated – Push/Pull | Center Closed (CC) | 1/8 NPTF |
| 01VL27CC03N | 5/3 | Lever Operated – Push/Pull | Center Closed (CC) | 1/4 NPTF |
| 01VL27OC02N | 5/3 | Lever Operated – Push/Pull | Opened Center (OC) | 1/8 NPTF |
| 01VL27OC03N | 5/3 | Lever Operated – Push/Pull | Opened Center (OC) | 1/4 NPTF |
| 01VL27PC03N | 5/3 | Lever Operated – Push/Pull | Pressure Control (PC) | 1/4 NPTF |
